Optic fiber sensor cable WT-GL-101

Short Description:

● Metal armored spiral sheath.

● Work with long term operation at -40℃ ~ +120℃ environment.

● Anti-corrosion, anti-tensile, abrasion resistant.

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Model:WT-GL-101

Description: The optic fiber sensor cable has the structure of metal armored spiral sheath, and it can work with long term operation at -40℃ ~ +120℃ temperature environment. Optic fiber is anti-corrosion, anti-tensile, abrasion resistant. So it can be used in harsh environmental condition for long time.

Product parameters:

Technical Parameters	Technical Data
Model	WT-GL-101
Optical fiber core diameter	62.5μm
Cladding diameter of the core	125μm
Insulation sleeve diameter	0.6mm
Outer sheath material	Low-smoke halogen-free flame retardant material, anti-static.
Line diameter	Φ3.0mm
Minimum bending radius	60mm
Sheath material	metal armored spiral sheath
Tensile strength	500N during installation300N during application
Compressive strength	5000N/10cm during installation 3000N/10cm during application
Deformation stress	300N/cm causes 0~0.3mm deformation
