Optic fiber Linear heat detector controller WT-GL-100C
Optic fiber Linear Heat Detector Model:WT-GL-100C
Description:
This kind of controller built-in optic fiber sensor module, industrial computer and touch screen. It uses DC24V power supply (or directly adopt fire power).
The functions are data display, temperature measurement, information storage and fire linkage etc.
The advantages are: small structure, easy to install, high stability, good compatibility, safety and reliablity.
Applications:
●Cable tray, Cable tunnel, Cable trench, High-voltage cable.
●Highway tunnel, Subway tunnel, Dam.
●Rail tunnel, Utility tunnel.
●Convey belt, Coal conveyor, Coal storage yard.
●Oil tank, Gas tank, Oil convey pipeline, Gas pipeline.
●Warehouse etc.
Technical Parameters:
| Technical Parameters | Technical Data |
| Model | WT-GL-100C |
| Number of Channels | 4 Channels |
| Single Channel Measurement Distance | 5km |
| Total Measurement Distance | 20km |
| Standard Alarm Length | 1m |
| Temperature Measurement Range | -40°C ～ +120°C (Depends on the Sensing Fiber) |
| Temperature Measurement Accuracy | ±1°C |
| Temperature Resolution | 0.1°C |
| Sampling Frequency | Typical 3s per Single Channel |
| Switching Quantity | 16-Channel Relay |
| Relay Capacity | 250VAC/3A |
| Communication Interface | RS485、RJ45 |
| Fiber Optic Connector | FC/APC Standard Fiber Optic Connector |
| Power Supply | 24VDC, 50W |
| Operating Environment Temperature | -10°C ～ +50°C
|
System connection diagram：
Application fields :
